Versa-Matic Hygienic and 3A Hygienic air-operated double diaphragm pumps are designed and certified for food, dairy, beverage, and pharmaceutical sanitary processing applications. The 3A-certified construction features polished stainless steel wetted components, crevice-free design, and FDA-approved diaphragms.

Gorman-Rupp 10 Series® self-priming pumps specifically designed for handling solids, corrosive liquids, and slurries. Ideal for industrial laundry, solids-laden and mildly corrosive service.

The Viking Pump 1127C Series is a stainless steel internal gear pump for hygienic, corrosive, and high-purity fluid transfer applications. All wetted components are 316 stainless steel, providing excellent resistance to a broad range of chemicals, food-grade fluids, and pharmaceutical products.

The Versa-Matic E2 Elima-Matic is a 2" ATEX-certified, bolted aluminum air-operated double diaphragm pump for use in explosive atmospheres and hazardous area classified locations. The Elima-Matic air distribution system eliminates stalling, providing smooth, reliable operation under low air supply conditions.

The NOV Moyno 2000 Series is a heavy-duty progressing cavity pump featuring a patented gear joint connecting rod design that eliminates the traditional pin joint and significantly reduces maintenance intervals. The 2000 Series delivers continuous, non-pulsating flow of highly viscous, abrasive, and shear-sensitive materials.

The Goulds Model 3171 is the industry's veteran vertical sump and process pump, with thousands of installations worldwide in industrial process, sump drainage, corrosive liquid handling, pollution control, and molten salt applications. API 610 11th edition VS4 compliant, the 3171 family covers the full range of vertical sump service from standard industrial drainage through severe corrosive and high-temperature process duties. The product line includes five variants: the standard 3171 (open impeller), CV 3171 (recessed impeller for solids and shear-sensitive fluids), LF 3171 (low-flow, high-head), NM 3171 (non-metallic for severe corrosives), and API 3171 (API 610 VS4 compliant for refinery and petrochemical service).

The Goulds Model 3196 i-FRAME is the industry's benchmark ANSI standard dimension back pull-out process centrifugal pump, first introduced in 1961 and proven across more than 1,000,000 installations worldwide. Users in chemical, petrochemical, pulp and paper, primary metals, food and beverage, oil and gas, water, and general industry consistently choose the 3196 for its exceptional reliability, ease of maintenance, and the lowest life cycle cost in its class. The i-FRAME Power End incorporates Goulds' patented intelligent monitoring technology and is backed by a standard 5-year warranty — a testament to its industry-leading design. As the only pump manufacturer to make digital condition monitoring standard on every process pump, ITT Goulds continues to set the standard for performance and innovation. The LF 3196 variant provides optimized hydraulics for low-flow process services where conventional end suction pumps would experience premature bearing and seal failure due to off-BEP operation.

The Goulds 3296 EZMAG is a heavy-duty sealless magnetic drive ANSI process pump engineered for zero-emission handling of corrosive, volatile, toxic, and difficult-to-seal process fluids. ANSI B73.1 dimensional compliant, the 3296 EZMAG is the ANSI-dimensioned expansion of ITT's successful ISO magnetic drive ICM pump, offering drop-in replacement capability for existing ANSI installations without requiring piping modifications. With no mechanical seal and a one-piece Hastelloy C containment shell rated to 2,175 PSI burst pressure, the 3296 EZMAG eliminates fugitive emission risk and ongoing mechanical seal maintenance costs. A fluoropolymer-lined variant handles the most severe corrosives cost-effectively, and a high-temperature variant with samarium cobalt magnets extends service to 535°F.

The Goulds 3298 is a sealless, magnetic drive ANSI process pump designed for zero-emission pumping of hazardous, toxic, and corrosive liquids. The sealless design completely eliminates the mechanical seal and its associated leakage risk, maintenance cost, and regulatory concerns. Available in a wide range of corrosion-resistant alloys and ETFE-lined construction.

Viking Motor Speed pumps are internal gear pumps designed to operate directly at motor speed (1,750 or 1,150 RPM) without speed reduction, providing a compact, cost-effective solution for direct motor-coupled applications. The motor speed design eliminates the cost of belt drives, couplings, and gear reducers.
